SMLIGHT SLZB-07p7 USB Zigbee Adapter

The SMLIGHT SLZB-07p7 is a compact USB Zigbee coordinator built around the Texas Instruments CC2652P7 Zigbee SoC. It is designed for smart home setups using Home Assistant ZHA or Zigbee2MQTT and comes pre-flashed for straightforward setup.

Extended-Range Zigbee Hardware

The SLZB-07p7 combines a CC2652P7 radio SoC with a +20 dB radio output and an external +3 dB rotatable antenna. Its 4-layer PCB helps separate the radio circuitry from USB-related interference, while the compact 18 × 54 × 10 mm design helps avoid blocking adjacent USB ports.

Home Assistant and Zigbee2MQTT Compatibility

The adapter is supported by Home Assistant ZHA and Zigbee2MQTT. It is pre-flashed and ready to use as a Zigbee coordinator, making it suitable for building and managing a Zigbee 3.0 smart home network.

Pre-Flashed and Easy to Update

The SLZB-07p7 supports CC2652P7 autoflash functionality and can be updated using SMLIGHT's web flasher. Firmware options depend on the supported firmware and operating mode; the device can also be flashed with compatible Thread firmware where supported.

Compact USB Zigbee Coordinator

• Texas Instruments CC2652P7 Zigbee SoC
• +20 dB Zigbee SoC output gain
• +3 dB external rotatable antenna
• CP2102N USB-to-UART interface
• Zigbee 3.0 support
• Pre-flashed for Home Assistant ZHA and Zigbee2MQTT
• CC2652P7 autoflash support
• 4-layer PCB designed for RF isolation from USB circuitry
• DIY pinouts for enthusiasts and custom projects
• Compact 18 × 54 × 10 mm form factor
• Operating environment: +5 °C to +35 °C

What's Included

• SMLIGHT SLZB-07p7 USB Zigbee Adapter
• External +3 dB rotatable antenna
• QR-code manual card
• Helper/setup guide

Important Compatibility Note

The SLZB-07p7 uses a single CC2652P7 radio SoC. Zigbee and Thread/Matter capabilities depend on the firmware installed; it should not be described as running Zigbee and Thread simultaneously on separate radios. For normal Zigbee use, the adapter is supplied pre-flashed for Zigbee coordinator operation.

Australian Local Support

We are an official Australian distributor for SMLIGHT products, providing local support and fast delivery within Australia.

Frequently Asked Questions

Does the SLZB-07p7 work with Home Assistant?

Yes. The SLZB-07p7 is designed to work with Home Assistant, including the ZHA integration.

Does the SLZB-07p7 work with Zigbee2MQTT?

Yes. The SLZB-07p7 is supported by Zigbee2MQTT and is supplied pre-flashed for Zigbee coordinator use.

What Zigbee chipset does the SLZB-07p7 use?

It uses the Texas Instruments CC2652P7 Zigbee SoC.

What antenna is included?

The adapter includes an external +3 dB rotatable antenna that can be positioned in three dimensions.

What is the USB interface chip?

The SLZB-07p7 uses a Silicon Labs CP2102N USB-to-UART interface.

Does the SLZB-07p7 support Zigbee 3.0?

Yes. Zigbee 3.0 support is provided out of the box with the pre-installed Zigbee firmware.

Can the firmware be updated?

Yes. SMLIGHT provides a web flasher for SLZB-07pX devices, including the SLZB-07p7.

Does it support Thread or Matter?

The CC2652P7 platform can be used with compatible Thread firmware. Thread/Matter operation depends on the installed firmware and supported configuration, rather than running as a second radio alongside Zigbee.

Do I need a USB extension cable?

SMLIGHT states that an extension cable is generally not required because the compact design is intended to reduce interference with nearby USB ports. A USB extension can still be used when positioning the antenna or adapter away from a computer or server is desirable.

What are the dimensions?

The SLZB-07p7 measures approximately 18 × 54 × 10 mm including the USB plug.

What is the operating temperature range?

The specified operating environment is +5 °C to +35 °C.

Technical Specifications

Manufacturer model number: SLZB-07p7
